Wet End, WW EX2 2.0hp 2"mbt 48fr

310-2460 Wet End, WW EX2 2.0hp 2"mbt 48fr Waterway EX2 Wet End

Side discharge, 2"mbt suction/discharge, 48 frame wet end for the Waterway EX2 pump. This wet end is used with a 2.0hp, 48 frame, thru-bolt style motor. The motor used may be either a single or dual speed. The wet end may be rotated 90° to change the discharge position. The complete wet end includes: the volute, seal, impeller, wear ring, suction cover, suction cover o-ring, drain plug, drain plug o-ring and suction cover screws. Motor and unions sold separately.

RECOMMENDED PARTS:

35-126-1025 Motor, Century, 2.0 Horsepower, 115v/230v, 1 Speed, 48 Frame

35-126-1119 Motor, Century, 2.0 Horsepower, 230v, 2 Speed, 48 Frame, EE

35-126-1120 Motor, Century, 2.0 Horsepower, 230v, 2 Speed, 48 Frame
