Wet End, WW EX2 1.5hp 2"mbt 48fr (1)

Wet End, WW EX2 1.5hp 2"mbt 48fr

SKU:
34-270-1738
$108.00
Write a Review
Description
310-2450 Wet End, WW EX2 1.5hp 2"mbt 48fr Waterway EX2 Wet End

Side discharge, 2"mbt suction/discharge, 48 frame wet end for the Waterway EX2 pump. This wet end is used with a 1.5hp, 48 frame, thru-bolt style motor. The motor used may be either a single or dual speed. The wet end may be rotated 90° to change the discharge position. The complete wet end includes: the volute, seal, impeller, wear ring, suction cover, suction cover o-ring, drain plug, drain plug o-ring and suction cover screws. Motor and unions sold separately.

RECOMMENDED PARTS:

35-126-1020 Motor, Century, 1.5 Horsepower, 115v/230v, 1 Speed, 48 Frame

35-126-1020W Motor, Century/WW, 1.5hp, 115v/230v, 1-Speed, 48 Frame

35-126-1116 Motor, Century, 1.5 Horsepower, 230v, 2 Speed, 48 Frame

88-375-1050 Lube Tube, Roper Products, 4oz, with PFTE

88-375-1050 Lube Tube, Roper Products, 4oz, with PFTE

88-426-1000 Lube, U.S. Seal, 10ml Tube
